Foxtech

D130 X8 V2 Frame

(No reviews) Write a Review
$999.00

SKU:
001293
Weight:
4.00 KGS

Based on D130 Version I‘s success, the strength and flight time of Version II are improved to meet higher requirements.
Removing Version I center damper plate, the strengthened center plate consists of 4mm carbon fiber plate with reinforcement ring and 4mm aluminum plate; the thickened arm tube is still 30mm in diameter but 2mm thickness now; the new landing gear system is with optimized standing angle which gives more space to take larger photography equipment, the optional dual landing gear makes landing still stable even with heavier load; two power systems are avaialble.
12S power system is formed with T-motor U8 KV100, T-Motor Flame 80A ESC and Foxtech Supreme 2880 Pro Propeller, under 12S, the take-off weight can reach 24kg maximum.
6S power system is formed with T-motor U8 KV170, Foxtech Multi-Pal 60A OPTO ESC and Foxtech Supreme 2880 Pro Propeller, under 6S, the take-off weight can reach 20kg maximum.
Foxtech D130 V2 brings all innovations, technology and experimental tests together to make such bright change.



Purchase Includes:
1x Foxtech Devourer 130 V2 Frame

Optional:
8x T-Motor U8 KV100 Motor
8x T-Motor U8 KV170 Motor
8x Foxtech Multi-Pal 60A OPTO ESC
8x T-Motor 80A ESC
4x Foxtech Supreme 2880 Pro Propeller
1x DJI A2 50Waypoints Combo Flight Controller/ ZeroTech Gemini Autopilot
1x Foxtech 300A Ultra Power Distributor
1x Foxtech Devourer130 Gimbal Loading Kit
1x Plug/Cable/Wires/Shrink Tubing etc
1x Futaba 14SG Radio Control
1x D130 Dual Landing Gear
1x Foxtech D130 Canopy (Available Soon)
8x Foxtech Motor Cover (Available Soon)
1x Foxtech Foldable GPS Seat




Diameter 1300 mm
Weight 12S: 7.2 kg (No Battery, No Gimbal)
               6S: 7.0 kg (No Battery, No Gimbal)
Max Take-off Weight 12S: 24 kg; 6S: 20 kg
Max PayLoad 12S: 16 kg (Include Battery)
  6S: 12 kg (Include Battery)
Max Flight Time 12S: 48 mins (No Load)
  6S: 50 mins (No Load)
