Halo-6000 EFI Generator for Hybrid Drone

Halo-6000 generator, using EFI engine and water-cooling system, features good heat dissipation, low power consumption and high efficiency and it’s specially designed for multicopters to ensure long endurance.

Smart Adjustments
Halo-6000 uses EFI engine which features consistent output power, better fuel efficiency, fewer emissions and less maintenance.

EFI engine can automatically adjust the fuel/air ratio via electronic controls to maintain optimal combustion conditions and determine the precise amount of fuel that the injector needs to deliver. By optimizing air/fuel ratios and ignition timing, EFI engine eliminates random engine stoppages and other problems associated with sub-optimal ratios, so it increases reliability and reduces the time and expense of maintenance.

High Efficiency
A monitoring software is provided to monitor the generator working status in real time. Compared with the internal rotor type generator, this external rotor type generator features aircraft-grade permanent magnetic brushless motor and high power-to-weight ratio (PWR). The engine is powered by double cylinder and two-stroke gasoline engine, which has the characteristics of high output power and low fuel consumption. The motor adopts an integrated external rotor motor, so there is no need of additional starter, as a result, the hybrid system has the advantages of one key starting, small volume, light weight and low noise.

Safe Operation
The protective design of the system controller for over voltage, over currency, over temperature, under voltage and short circuit, substantially improves its safety.

Good Heat Dissipation Performance
Halo-6000 uses water-cooling system, including two radiators, a water jacket, a water pump and water pipes. Compared with air-cooling system, it’s more durable and powerful.

Note: The motor oil used for Halo-6000 should be MOTUL 710 2T, or motor oil appointed by Foxtech. If the damage is caused by the wrong use of motor oil, Foxtech will not be responsible for it.
The battery for Halo-6000 should be 3C or higher.
There should be lubricating oil on both ports of the oil filter, or there may be air goes into the fuel pipe.

Your Purchase Includes:
1x Halo-6000 Generator
1x 4.5L Fuel Tank
1x Fuel Level Sensor
1x Fuel Pipe
1x Fuel Mixer
1x Water Pipe
1x System Controller Cable
1x Fuel Pump
1x Water Pump
1x Water Jacket
2x Radiator
1x ECU Cable
2x 7S 12000 Battery
