Note: If you have any customization requirements for Krane 130, please reach out to our sales or send us an email.
Krane 130 is a modular-design electrical quadcopter with a 10 kg loading capacity, which makes it an ideal platform for inspection, delivery and dropping.
The whole UAV adopts a modular design with the arms, the batteries, the mission payloads, and the propellers, so it is possible to assemble it within 3 min by one operator.
Krane 130 can equip with dual GPS for easier flight preparation and higher positioning accuracy.
Quick-mount structure for the mission payloads mounting, such as gimbal camera, LiDAR scanner, cargo delivery box, cargo release and drop device, megaphone, light, etc., allows multiple-mission-payload-mounting to carry out one task, such as synchronized inspection with upward-mounted and downward-mounted gimbal cameras, cargo delivery using a winch and LiDAR, etc.
Highlights:
10KG Loading Capacity
Modular Design
Your Purchase Includes:
1x Krane 130 Quadcopter
1x GPS Module
1x Flight Controller
1x Ground Control Station
2x 7S 28000mAh Battery
1x Battery Charger
1x Carrying Case
Optional Components:
GPS Module: Dual GPS, etc.
Radio Controller: MX16 Pro(30 km), etc.
Mission Payload: mapping/filming cameras, inspection gimbal cameras, LiDARs, RTK modules, cargo release & drop devices, cargo delivery boxes, megaphones, lights, etc.

| Version | Krane-130 Electrical Quadcopter |
| Wheelbase | 1250 mm |
| Size | 1040*1040*270 mm(Unfolded) |
| Propeller | 32*12 |
| Basic Empty Weight | 4 kg(Exclude battery) |
| Endurance | 120 min @ no payload |
| 90 min @ 1 kg payload | |
| 60 min @ 5 kg payload | |
| 30 min @ 10 kg payload | |
| Max Take-off Weight | 20 kg |
| Max Roll Angle | 150° |
| Max Pitch Angle | 25° |
| Climb Speed | 3 m/s |
| Descend Speed | 2.5 m/s |
| Max Speed | 15 m/s |
| Service Ceiling | 5500 m |
| Wind Resistance | Level 7 |
| Storage Temp | -10~45℃ |
| Working Temp | -20~45℃ |
| Battery | 2* 7S 28000 mAh |
| Working Voltage | 25.2V(7S) |
| Material | Carbon Fiber, CNC, etc. |
| Carrying Case | 1150*420*355 mm |
