Diamond Battery
Diamond 4.45V Ultra-Low Temperature Series Semi-solid-state Li-ion battery 6S/12S/14S/18S/24S 22000mAh~134000mAh
- SKU:
- S241113
- Weight:
- 10.00 KGS
Note: Please contact sales before placing your order.
Diamond HVT Series Ultra-Low Temperature Semi-Solid-State Battery, designed for exceptional performance in extreme cold environments.
The Diamond HVT Series Semi-Solid-State Li-Ion Battery features an enhanced charging voltage of 4.45V per cell, delivering increased power output for demanding applications. This advanced design provides superior energy capacity and efficiency, making it ideal for high-performance needs.
Diamond HVT Series battery features an impressive energy density of up to 300 Wh/kg (available in 67,000mAh and 134,000mAh configurations), and supports a peak discharge rate of up to 20C (22,000mAh, 35,000mAh, 36,000mAh, 44,000mAh, and 88,000mAh).
Built to withstand temperatures as low as -40°C, the Diamond HVT Series combines high energy density with reliable power output, even in the most demanding conditions.
Note: QS8-S Plug (Default)
Highlights:
4.45V Per Cell
High Energy Density
High Discharge Rate
1000 Times Cycle
-40℃~60℃ Working Temperature
Your Purchase Includes:
1x Diamond HVT Ultra-Low Temperature Semi-Solid-State Li-ion Battery
(6S/12S/14S/18S/24S 22000mAh~134000mAh)
Warnings:
Do not overcharge or over-discharge.
Single cell cutoff voltage is 3.55V~3.6V.
Do not store at full charge.
Do not crush, disassemble, or burn.
Strictly follow the battery instructions. Improper use is at user's own risk.
Voltage | 47.4 V |
Capacity | 66000 mAh |
Max Discharge Rate | 15C |
Charge | 1C |
Power | 3128.4 Wh |
Energy Density | 292 Wh/kg |
Size | 250*165*126 mm |
Weight | 10650g |
Plug | QS8-S |
